Tire pressure is a crucial aspect of safe and efficient driving. Underinflated or overinflated tires can compromise vehicle handling, fuel economy, and safety. To address this issue, the 2017 Honda HR-V features a Direct Tire Pressure Monitoring System (TPMS). This system is designed to provide drivers with real-time tire pressure readings, allowing them to take action when necessary. In this article, we will explain how the 2017 Honda HR-V TPMS works, how to reset it, its components, operation, and maintenance.
Honda TPMS Components
The 2017 Honda HR-V TPMS consists of the following components:
Tire Pressure Sensors: These sensors are installed inside each tire and are responsible for measuring tire pressure. The sensors transmit the pressure readings wirelessly to the TPMS control unit.
TPMS Control Unit: The control unit receives the pressure readings from the tire pressure sensors and processes the information. It then sends the tire pressure data to the instrument cluster and the warning light.
Warning Light: The warning light is located on the instrument panel and alerts the driver of low tire pressure. If the warning light illuminates, the driver should check the tire pressure and inflate the tires to the recommended level.
How to Reset the Honda HR-V TPMS:
Before following this procedure, be sure your tires are at the recommended pressure levels.
Car ignition ON or have the vehicle running.
Hold down the TPMS button. (located below the GREEN ECON button on the left of the steering wheel)
The tire pressure light will start flashing.
After the tire pressure light stops flashing, release the TPMS button.
Honda HR-V TPMS Operation
When the ignition is turned on, the tire pressure sensors activate and begin transmitting tire pressure data to the TPMS control unit.
The control unit receives the tire pressure readings and compares them to the recommended tire pressure for the vehicle.
If the tire pressure is below the recommended level, the warning light illuminates on the instrument cluster.
If the tire pressure is at or above the recommended level, the warning light remains off.
If the tire pressure drops significantly, the warning light will flash, indicating a severe loss of tire pressure.
When to Reset the Tire Pressure Monitoring System
After filling or adjusting tire pressure: Whenever you fill or adjust the tire pressure, you should reset the TPMS so that it can accurately monitor the new pressure readings. Always adjust tire pressures when tires are cold, before driving long distances.
After rotating tires: If you rotate your tires, you should reset the TPMS so that it can properly monitor the new tire locations and pressure readings.
After replacing a tire: If you replace a tire, you should reset the TPMS so that it can accurately monitor the pressure readings of the new tire.
After replacing a tire pressure sensor: If you replace a tire pressure sensor, you should reset the TPMS so that it can accurately receive the new sensor’s readings.
After replacing the TPMS control unit: If you replace the TPMS control unit, you should reset the TPMS so that it can properly receive and interpret the tire pressure readings.
After a TPMS malfunction: If the TPMS malfunctions, you may need to reset it to clear any error codes and restore normal function.
Common Causes for Tire Light to Turn On
Faulty tire pressure sensor: If one of your tire pressure sensors is faulty or damaged, it may send incorrect pressure readings to the TPMS control unit, causing the warning light to turn on.
Low tire pressure: If one or more of your tires is underinflated, the tire pressure warning light may turn on to alert you to the low pressure. We recommend this tire pressure gauge.
Temperature changes: Extreme temperature changes can affect tire pressure. If the temperature drops suddenly, it can cause the air in your tires to contract, resulting in lower tire pressure and a triggered warning light.
Punctured or damaged tire: A punctured or damaged tire can cause a loss of tire pressure, triggering the tire pressure warning light.
Improper tire installation: If your tires are not installed correctly or if the valve stems are damaged or leaking, it can cause a loss of tire pressure and trigger the warning light.
TPMS malfunction: In some cases, the TPMS control unit itself may malfunction, causing the warning light to turn on even if there are no issues with the tire pressure.
Honda HR-V TPMS Maintenance
To ensure the proper functioning of the 2017 Honda HR-V TPMS, it is essential to perform regular maintenance, including:
Checking tire pressure regularly: The tire pressure should be checked at least once a month and before long trips. The recommended tire pressure can be found in the owner’s manual or on a sticker located on the driver’s side door jamb. (the yellow and white sticker)
Replacing damaged sensors: If a tire pressure sensor is damaged, it should be replaced immediately. Damaged sensors and tire valves can compromise the accuracy of the tire pressure readings. (To determine if a sensor is faulty, use a tool like this, or bring your car to your local mechanic)
Replacing faulty sensors: Tire pressure sensors use batteries, which can eventually die. Sensor batteries usually last about 7-10 years. If a tire pressure sensor battery dies, the sensor must be replaced.
Frequently Asked Questions (FAQs)
How accurate is the 2017 Honda HR-V TPMS?
The 2017 Honda HR-V Direct TPMS is very accurate and can detect even small changes in tire pressure.
Can the 2017 Honda HR-V TPMS be reset?
Yes, the 2017 Honda HR-V Direct TPMS can be reset by following the instructions in the owner’s manual.
Can the 2017 Honda HR-V TPMS be disabled? No, the 2017 Honda HR-V Direct TPMS cannot be disabled. It is a required safety feature.
Conclusion
The 2017 Honda HR-V TPMS is a vital safety feature that provides drivers with real-time tire pressure readings. The system consists of tire pressure sensors, a TPMS control unit, and a warning light. By constantly monitoring tire pressure, the 2017 Honda HR-V TPMS helps ensure safe and efficient driving. To make sure the system is functioning correctly, it is essential to perform regular maintenance, including checking tire pressure and replacing damaged sensors. With its advanced technology and user-friendly design, the 2017 Honda HR-V TPMS is a valuable addition to any driver’s safety arsenal. So, if you’re driving a 2017 Honda HR-V, make sure you understand how the TPMS works and keep your tires properly inflated to enjoy a safe and smooth ride.
