ALFA ROMEO TONALE TIRE PRESSURE LIGHT

How to Reset and Troubleshoot Alfa Romeo Tonale Low Tire Pressure Light

STEPS TO RESET ALFA ROMEO TONALE TIRE PRESSURE MONITORING SYSTEM

  1. Inflate all 4 Alfa Romeo tires to the recommended tire air pressure found on the inside of the driver side door.

  2. Drive for at least 5-10 minutes at speeds above 15 Mph (24 kmh).

  3. dsgffdsg

WHAT TO DO IF THE aLFA rOMEO tONALE TPMS RESET PROCEDURE DID NOT WORK?

In the event that the Alfa Romeo Tonale TPMS reset process fails to reset the tire pressure warning light, shut off the engine and double check your tire pressure to confirm that all tires are at the exact pressure you set them to. Sometimes it can take driving for up to 15 minutes for the low tire light to turn off.

WHY DIDN'T THE ALFA ROMEO TPMS RESET PROCESS WORK?

There are 4 main causes why the Alfa Romeo Tonale tire pressure reset process did not work:

  1. Alfa Romeo Tonale TPMS may fail to recalibrate correctly if the tires are losing or low on air. It’s crucial to manually verify the tire pressure in each tire. Observing a reduction in air pressure from previous measurements may indicate a leak.

  2. Alfa Romeo tire pressure monitoring sensors with low or dead batteries can also lead to issues. Employing a  special TPMS diagnostic tool is essential for pinpointing the defective sensor.

  3. Driving with the spare tire on. The spare tire in the Alfa Romeo does not have a tire pressure sensor within it. This means driving while the spare tire is on the car will cause the low tire pressure light to turn on and stay on.

  4. There are instances when tire pressure sensors become inoperative, even if their batteries are still functional. To address this, inflate the tires by an additional 10 Psi (at least) beyond their normal level, then gradually release the air.

WHAT IS THE ALFA ROMEO TPMS?

The Alfa Romeo Tonale tire pressure monitoring system is crucial for maintaining optimal performance and safety, as it ensures tires maintain the correct pressure. Equipped with a tire sensor in each tire, the vehicle incorporates four sensors in total, which synchronize with a dedicated TPMS receiver module linked to the vehicle’s on-board computer system (ECU). This system is integral not only for convenience but also as a key aspect of Alfa Romeo’s safety protocols.

HOW DOES THE ALFA ROMEO TPMS WORK?

ALFA ROMEO TIRE PRESSURE SENSORS

Each Alfa Romeo Tonale tire pressure sensor is housed in a compact plastic case attached to the valve stem. This device is made up of a microcontroller, a battery for power, a pressure transducer for measuring tire pressure, and a built-in transmitter equipped with an antenna.

HOW DOES A TIRE PRESSURE SENSOR WORK?

  1. Pressure Transducer: Converts the tire pressure into an electrical signal.

  2. Microcontroller: Processes the electrical signal from the pressure transducer, converting it into data that can be understood.

  3. Transmitter and Antenna: Enables the wireless sending of data to the Alfa Romeo Tonale TPMS receiver module.

In simpler terms, the microcontroller, which is a small chip powered by a battery, measures the tire’s air pressure. Then, the data is transmitted to the Alfa Romeo’s TPMS receiver module using a specific radio frequency by the transmitter.

ALFA ROMEO TONALE TPMS RECEIVER MODULE

The TPMS receiver module plays a vital role in the system by gathering air pressure data from the sensors in each tire and then relaying this information to the Alfa Romeo Tonale’s on-board computer.

  1. Collecting Signals from Tire Sensors: The Alfa Romeo Tonale’s TPMS receiver module is located inside the car, typically under the dashboard or near the middle console. As the Alfa Romeo drives, its tire sensors transmit information that the receiver module picks up for ongoing monitoring.

  2. Processing and Matching Data: Once a signal is received, the TPMS receiver module processes the information. It decodes the signal to extract tire pressure levels and identifies which tire the information is coming from.

ALFA ROMEO TONALE ON BOARD COMPUTER

The Alfa Romeo Tonale on-board computer (ECU) is essential for processing tire pressure data. It receives this data from the TPMS receiver module and compares it against Alfa Romeo’s manufacturer recommended air pressure guidelines. If any tire’s pressure significantly deviates from these guidelines, the ECU activates a warning. This alert can appear on the dashboard as a tire pressure figure, a low-pressure indicator light, or a message on the display screen. Furthermore, the ECU displays real-time tire pressure readings on the Alfa Romeo Tonale’s information display screen.

ALFA ROMEO TONALE TIRE PRESSURE AND SIZE

TIRE SIZE

Front Psi/Bar

Rear Psi/Bar

235/50R18

35/2.4

32/2.2

WHAT TO DO FIRST IF YOUR ALFA ROMEO TIRE LIGHT TURNS ON

If your Alfa Romeo Tonale low tire pressure light turns on, promptly pull over to a safe spot and check your tires’ pressure with a digital gauge. Look over each tire and wheel for any visible problems. Should the Tonale low tire pressure light turn off after you’ve corrected the tire pressures to the right Psi, this indicates that the Alfa Romeo tire pressure monitoring system is working properly.

WHY IS THE ALFA ROMEO TONALE LOW TIRE PRESSURE LIGHT ON?

  • High or Low Tire Pressure: The tire light can turn on if the pressure is either above or below the recommended level.

  • Using the Spare Tire: The light will activate when driving on the spare tire.

  • Dead TPMS Sensor Batteries: When the Tonale tire sensor batteries are dead or failing.

  • TPMS Receiver or Vehicle Computer Issues: Problems within the receiver’s hardware or software, or the ECM/ECU.

  • Electronic Interferences: Electronic devices like phones, alarms, or radios causing signal disruption.

  • Significant Temperature Shifts: Changes in air temperature affecting tire pressure.

  • Overloading the Vehicle: Exceeding the vehicle’s weight capacity or towing limit.

  • Tire Chains Usage: Chains can interfere with pressure readings.

  • Too Much Window Tint: Overly dark window tint can block signals between the receiver and sensors.

  • Road Temperature Changes: Fluctuations in road surface temperature.

  • Wrong Tire Size or Type: Tires not matching Alfa Romeo Tonale’s manufacturer specifications.

  • TPMS Sensor or Valve Damage: Damage from tire changes or maintenance.

  • Failure to Recalibrate TPMS: Not resetting/driving the system post-maintenance.

  • Tire Punctures or Leaks: Air loss from leaks or punctures.

  • Tire or Wheel Damage: Harm from road debris or wear.

WHY COLD TIRES ARE IDEAL FOR CHECKING & ADJUSTING TIRE PRESSURE

For accurate and safe tire pressure levels, it’s important to check and set your tire pressure when the tires are cold, following the guidelines provided by the manufacturer. Tire pressure can rise by 4-5 psi when tires warm up from driving. This can result in incorrect air pressure readings. The best time to measure or adjust tire pressure is when the tires are cold, which means they haven’t been driven on recently or have been stationary for at least 3 hours. This difference between warm and cold tires can result in accidentally overinflating the tires.

ALFA ROMEO TONALE TIRE PRESSURE SENSOR BATTERY LIFE

Every Alfa Romeo Tonale tire pressure sensor uses a non-replaceable, non-rechargeable silver oxide battery. Tire pressure sensor batteries have a life expectancy of 5 to 15 years, or about 100,000 to 150,000 miles. When the battery in a sensor dies, the whole TPMS sensor needs to be replaced. To check the condition of the Alfa Romeo Tonale tire pressure sensor batteries, you must use a special TPMS tool.

WHAT ARE SPECIAL TPMS TOOLS?

TPMS diagnostic tools are advanced devices designed to communicate with the TPMS sensors in a vehicle. They work by sending a radio frequency (RF) signal to the sensor, prompting it to return data like tire pressure, temperature, battery status, signal strength, and the sensor’s ID number. The tool then displays this information, allowing technicians to evaluate the functionality and health of each TPMS sensor. These tools are crucial for detecting issues such as sensor malfunctions or battery depletion. Moreover, the more sophisticated versions of these tools can reprogram sensors, update their software, or assist in a relearning process that helps the vehicle’s computer system recognize new sensors.

USING TPMS DIAGNOSTIC TOOLS

After analyzing the information provided by the TPMS diagnostic tool, a sensor that shows low battery power or sends incorrect information (such as reporting 0 psi when the actual tire pressure is 35 psi) requires a replacement. The newly installed tire pressure sensor then needs to be programmed to synchronize with the ECU of the Alfa Romeo Tonale.

TRICKS TO FIX FALSE LOW TIRE PRESSURE LIGHT ALERTS

If the tire pressure sensors are working properly but the low tire pressure warning light stays on:

  • Inflate all tires to around 40-45 Psi, which is about 10 Psi above the usual pressure.

  • Slowly release air from each tire until the pressure drops to about 35 Psi.

  • Drive the Alfa Romeo Tonale for about 10 minutes.

  • Then, deflate the tires to set the air pressure back to the recommended values.

  • Drive the car a second time.

IS IT SAFE TO DRIVE THE ALFA ROMEO TONALE WITH THE LOW TIRE LIGHT ON?

No, it’s unsafe to drive your Alfa Romeo Tonale with underinflated or overinflated tires. It’s crucial to quickly repair or replace a tire that is losing air. However, if the low tire pressure warning is due to a dead sensor battery, you can still drive safely as long as the actual tire pressures are within the recommended range.

HOW FAR CAN YOU DRIVE THE ALFA ROMEO TONALE WHEN THE TIRE LIGHT IS ON?

When the Alfa Romeo Tonale low tire pressure warning light turns on, there’s no set distance limit or time that’s safe to keep driving. You should stop as soon as you can, visually check each tire, and check their air pressures one by one with a digital tire pressure gauge. It’s not advisable to rely only on the tire pressure information displayed by the vehicle’s information display screen.

HOW TO HANDLE ALFA ROMEO TIRE PRESSURE SENSORS WHEN CHANGING WHEELS

If you plan to replace the wheels or rims on your Alfa Romeo Tonale, there are a few options available:

  1. Move the existing Alfa Romeo Tonale tire pressure sensors from the original wheels to the new ones.

  2. Opt for programmable tire pressure sensors (like those from Autel), install them on the new wheels, and then program and sync them with your Alfa Romeo Tonale’s onboard computer. You’ll need a TPMS programming tool for this.

  3. Follow the standard procedure to reset the Alfa Romeo Tonale tire pressure warning light after replacing the tires.

WHY IS THE ALFA ROMEO TIRE LIGHT FLASHING?

If your Alfa Romeo Tonale low tire pressure warning light is flashing, it signifies a disruption in the communication between the car’s ECU and at least one of the tire pressure sensors, indicating a TPMS malfunction. This problem typically stems from one of three key causes:

  • Use of the vehicle’s spare tire, which does not have a TPMS sensor.

  • A tire pressure sensor battery is either completely dead or nearly out of power.

  • A tire pressure sensor is defective or damaged, preventing it from communicating properly with the Alfa Romeo TPMS .

WILL THE WEATHER SET OFF THE ALFA ROMEO LOW TIRE PRESSURE WARNING?

The low tire pressure warning light often turns on with changes in weather conditions. Tire pressure can vary by about 1 Psi for every 10°F change in the surrounding air temperature. For example, if the air temperature falls by 42°F within a 5 week period (Fall to winter), your Alfa Romeo Tonale tire pressure would drop from 35 Psi to 30 Psi, setting off the low tire pressure indicator light.

WHY THE ALFA ROMEO TIRE LIGHT IS ON WHEN THE TIRES SEEM OKAY

Don’t just use visual checks to assess the state of your tires. It’s crucial to measure your Alfa Romeo Tonale tire air pressure using a digital tire pressure gauge, particularly when you suspect an issue. If the low tire pressure warning light turns off after you inflate the tires, it confirms that the Alfa Romeo Tire Pressure Monitoring System is working as it should. If the air pressure in all tires is correct and the light is still on, we recommend using a TPMS diagnostic tool to determine what the problem is.

FIND A LEAKING TIRE USING SOAP, WATER, & A SPRAY BOTTLE

To accurately locate a tire leak, use the following method:

  1. Inflate the tire you think might be leaking to 40 Psi or more.

  2. Prepare a soapy mixture by combining water and soap in a spray bottle.

  3. Generously apply the soapy solution to the entire tire, paying special attention to the bead and valve stem areas.

  4. Look for the formation of bubbles and follow them to pinpoint the exact spot of the leak.

  5. Mark the leak’s location on the tire with chalk.

STEPS TO RESET THE ALFA ROMEO TONALE TPMS BY DISCONNECTING THE BATTERY

If your Alfa Romeo Tonale low tire pressure warning light stays on after trying to reset it and adjusting the tire pressures, you might need to disconnect the car’s main 12-volt battery to clear any TPMS errors in the ECU. Do the following:

  1. Turn off the engine and all electronic devices (like the radio and lights).

  2. Detach the negative terminal of the battery.

  3. Wait briefly before reattaching the terminal, ensuring it’s firmly in place.

This action should reset the TPMS and extinguish the low tire pressure light. However, if the low tire light comes back on while you’re driving, this could suggest a problem with a tire pressure sensor or a slow air leak in a tire.

DOES TIRE AIR PRESSURE AFFECT GAS MILEAGE?

Maintaining the recommended tire pressure for your Alfa Romeo Tonale is essential for achieving optimal fuel economy. Underinflated tires increase rolling resistance, requiring the engine to use more energy and thus consume more fuel. A decrease in tire pressure by 10 psi can lead to a roughly 2% drop in fuel efficiency. Although this figure might seem small, it can result in significant fuel cost increases over time.

FAQ

CAN THE ALFA ROMEO TPMS BE DISABLED?

No, the Alfa Romeo Tonale TPMS is a safety feature, it is permanently active and cannot be deactivated. If you replace the Alfa Romeo’s tire pressure sensors with valve stems that lack sensors, the tire pressure warning light will first flash and then stay on.

IS THE LOW TIRE PRESSURE LIGHT TRIGGERED BY CHANGES IN ALTITUDE?

No, driving your Alfa Romeo Tonale to higher elevations typically does not trigger the tire pressure warning light. As altitude increases, the pressure inside the tires also tends to rise, expecting an increase of about 0.5 Psi for every 1,000 feet of elevation gained.

TIRE PLUGS VS. TIRE PATCHES

Having worked as an automotive technician for ten years, I often use tire plugs to repair punctures and have found them to be reliable and effective when used correctly. However, it’s crucial not to use tire plugs on tires with considerable tread wear or punctures on the sidewall. For larger punctures or leaks, choosing a tire patch or replacing the tire entirely is recommended.

PRO TIP: Opt for high-quality tire plugs. Low-quality plugs tend to fail quickly and are best avoided.

CAN TIRE SEALANTS BREAK TIRE PRESSURE SENSORS?

Yes, using tire sealants (like fix-a-flat) can damage tire pressure sensors. While sealants can serve as a temporary fix, it’s important to visit a service center soon after to have the tire properly cleaned and the tire pressure sensors checked to make sure they’re still working correctly.

ABOUT THE AUTHOR

STEFAN A.

Professional Automotive Technician – I am currently an automotive technician in New Jersey and have worked in private shops as well as dealerships for the past 10 years. When I am not writing articles I am wrenching on race cars and driving radio controlled cars at the track!

Everything in this article is applicable to all Alfa Romeo Tonale models and versions built between 2022-2025.
